EPS detail RB4

Midspan Beam Roof Connection at Panel Break

Roof Panel Spline at Midspan Beam — the manufacturer's designation for this condition. Drawing is not to scale; download the PDF for the full sheet.

Roof Panel Spline at Midspan Beam construction detail drawing with callouts

Roof Panel Spline at Midspan BeamRB4 · N.T.S.

Detail: RB4
Name: Roof Panel Spline at Midspan Beam
Group: Ridge & Beam
Scale: N.T.S.
Source: Energy Panel Structures, Inc.

Free, no signup. Confirm conditions against your engineer's requirements and local code.
