Murus detail 7A

Typical Inlet Nailer Connection Detail

Typical Inlet Nailer Connection Detail — the manufacturer's designation for this condition. Drawing is not to scale; download the PDF for the full sheet.

Typical Inlet Nailer Connection Detail construction detail drawing with callouts
Typical Inlet Nailer Connection Detail7A · N.T.S.
Detail
7A
Name
Typical Inlet Nailer Connection Detail
Group
Walls
Scale
N.T.S.
Source
The Murus Company, Inc.

Download PDF

Free, no signup. Confirm conditions against your engineer's requirements and local code.
