EPS detail RP3

Beveled Top Plate Roof Connection Detail - Square Cut

Beveled Top Plate / Sq Cut Eave — the manufacturer's designation for this condition. Drawing is not to scale; download the PDF for the full sheet.

Beveled Top Plate / Sq Cut Eave construction detail drawing with callouts
Beveled Top Plate / Sq Cut EaveRP3 · N.T.S.
Detail
RP3
Name
Beveled Top Plate / Sq Cut Eave
Group
Roof / Wall Connections
Scale
N.T.S.
Source
Energy Panel Structures, Inc.

Download PDF

Free, no signup. Confirm conditions against your engineer's requirements and local code.
